Vibes TP

  • - Direct and indirect light with transparent diffuser and non-yellowing PMMA light guide
  • - 130lm/W, available light panel length 1.2m, 1.5m, and 1.8m
  • - 5 Years Warranty; CE, RoHS2.0, REACH approval
  • Product description:Cyanlite LED panel Vibes TP family for direct and indirect light by suspended installation, 130lm/W, available length 1.2m, 1.5m and 1.8m, non-yellowing PMMA LGP; UGR<19; transparent appearance.
  • Inquiry

Cyanlite direct and indirect light LED panel transparent Vibes TP

The Cyanlite™ direct and indirect light LED panel Vibes TP series is an edge-lit luminaire for both direct and indirect light. Thanks to transparent diffuser and non-yellowing PMMA LGP, light distribution achieves 50% downwards and 50% upwards, UGR<19 with pleasantly smooth light. Suspended mounting as a single or continuous line luminaire is possible. Exquisite design via driver in the canopy and tidy wires.

Cyanlite direct and indirect light transparent LED panel Vibes TP

Advantages

-          Direct and indirect light for harmonious luminous environment

-          Transparent appearance achieving a space of penetration and low glare

-          Suspended luminaire with diverse applications

-          Driver in the canopy and tidy wires for a classy appearance

-          Customization oriented, bespoke sizes are welcome

-          Professional LED lighting manufacturer, ODM for EU top lighting brands, no risk for partnership

Features

l   50% upwards and 50% downwards, transparent appearance

l   Standard sizes (mm): 300x1200, 250x1200, 250x1500, 250x1800

l   RAL9016 white as standard, other RAL colors available on request

l   System Efficiency upto 130lm/W

l   EN 12464-1& LG7 Compliant, UGR<19 Optional when fitted with Micro Prismatic diffuser

l   Range of color temperatures 3000K, 3500K, 4000K, 5000K & 6000K

l   5 Years Warranty

l   Various dimming options, including 0-10V, DALI, Switch Dim etc.

l   Emergency options available

Specifications

Model

Part No.

Power

Luminous Flux

Dimension

Efficiency @ 4000K

300x1200

PS30W312P-xyyTP

30W

1950lm↑ 1950lm↓

295x1195x15 mm

130lm/W

250x1200

PS30W212P-xyyTP

30W

1950lm↑ 1950lm↓

245x1195x15 mm

130lm/W

250x1500

PS40W215P-xyyTP

40W

2600lm↑ 2600lm↓

245x1495x15 mm

130lm/W

250x1800

PS45W218P-xyyTP

45W

2925lm↑ 2925lm↓

245x1795x15 mm

130lm/W

- Light Distribution

Cyanlite direct indirect LED panel light transparent Vibes TP

Certifications


• Downloads


Cyanlite direct and indirect light LED panel transparent Vibes TP datasheet/installation manual/photometric data download
