  • - Direct and indirect light with opalic diffuser and non-yellowing PMMA light guide
  • - 130lm/W, available light panel length 1.2m, 1.5m, and 1.8m
  • - 5 Years Warranty; CE, RoHS2.0, REACH approval
  • Product description:Cyanlite LED panel Vibes UD family for direct and indirect light by suspended installation, 130lm/W, available length 1.2m, 1.5m and 1.8m, non-yellowing PMMA LGP.
  • Inquiry

Cyanlite direct and indirect light LED panel Vibes UD

The Cyanlite™ direct and indirect light LED panel Vibes UD series is an edge-lit luminaire for both direct and indirect light. Thanks to opalic diffuser and non-yellowing PMMA LGP, light distribution achieves 70% downwards and 30% upwards, so that there is competent luminous intensity on workplane and harmonious light to the ceiling. Suspended mounting as a single or continuous line luminaire is possible. Exquisite design via driver in the canopy and tidy wires.

Cyanlite LED direct and indirect panel light Vibes

Cyanlite LED direct and indirect panel light Vibes

Advantages

-          Direct and indirect light for harmonious luminous environment

-          Suspended luminaire with diverse applications

-          Driver in the canopy and tidy wires for a classy appearance

-          Customization oriented, bespoke sizes are welcome

-          Professional LED lighting manufacturer, ODM for EU top lighting brands, no risk for partnership

Features

l   30% upwards and 70% downwards with opalic and micro prismatic optional

l   Standard sizes (mm): 300x1200, 250x1200, 250x1500, 250x1800

l   RAL9016 white as standard, other RAL colors available on request

l   System Efficiency upto 130lm/W

l   EN 12464-1& LG7 Compliant, UGR<19 Optional when fitted with Micro Prismatic diffuser

l   Range of color temperatures 3000K, 3500K, 4000K, 5000K & 6000K

l   5 Years Warranty

l   Various dimming options, including 0-10V, DALI, Switch Dim etc.

l   Emergency options available

Specifications

Model

Part No.

Power

Luminous Flux

Dimension

Efficiency @ 4000K

300x1200

PS30W312P-xyyUD

30W

1170lm↑2730lm↓

295x1195x15 mm

130lm/W

250x1200

PS30W212P-xyyUD

30W

1170lm↑2730lm↓

245x1195x15 mm

130lm/W

250x1500

PS40W215P-xyyUD

40W

1560lm↑3640lm↓

245x1495x15 mm

130lm/W

250x1800

PS45W218P-xyyUD

45W

1755lm↑4095lm↓

245x1795x15 mm

130lm/W

- Light Distribution

Cyanlite direct indirect LED panel light Vibes UD

Certifications


• Downloads


Cyanlite direct and indirect light LED panel Vibes UD datasheet/installation manual/photometric data download
